工業檢測光學鏡頭 / CS-Mount
F1250 series(長焦)

No. FR-TH-F1250


Theia 1250 Series

4K resolution telephoto lens: F1250S

4K motorized telephoto lens: F1250T

簡介

F1250S / F1250T 系列是高品質鏡頭,鏡頭專為4K相機而設計,旨在讓安裝人員充分利用4K ,HD 和百萬畫素高解析度。該鏡頭可用於高達1200萬畫素解析度(true 4K) 的相機,從邊緣到邊緣提供清晰的影像。True 4K 解析度長焦鏡頭用於長距離安防監控和車牌辨識(LPR)應用。

F1250S 提供電動 / 手動光圈和 CS-mount ,而 F1250T 包括電動變焦和對焦,搭配電路板安裝。

具有 12 - 50 mm 的變焦距離和卓越的影像性能,適用於 1 / 2.3" 至 1 / 1.7" 的 Sensor 。 鏡頭設計可適用於小型相機。 如 4" 半圓監視器。

特色

  • Ultra high resolution for 4K cameras, up to 12.4 megapixel
  • Available in DC autoiris, P-iris, and manual iris versions
  • Fully motorized versions, or combinations with zoom, focus, iris, IR cut, limit switch; non-motorized versions also available
  • IR corrected for true Day/Night cameras
  • Compact design to fit into domes as small as 4” mini-dome size
  • CS-mount and smooth D25 board mount options
  • Used for sensor sizes 1/2.5”, 1/2.3”, 1/2" 1/1.8”, and up to 1/1.7” (Sony IMX178, Sony IMX226 for example)

範例

Entry door Building entry
F1250S F1250S at 50mm
Parking lot entry Parking lot entry
F1250S at 12mm F1250S at 50mm
Squirrel cam

F1250S (squirrel cam) 50mm



規格

F1250 series lenses

Lens model 1250SA 1250SP 1250SM 1250TA 1250TP
Iris type DC autoiris P-iris Manual iris DC autoiris P-iris
Focal length 12mm -50mm varifocal
IR correction Day / Night
Mount type CS-mount CS-mount CS-mount CS-mount or D25 board mount
F/# F/1.8 to closed
Resolution true 4K resolution, 12MP
Image sensor size 1/2.3" up to 1/1.7"

Lens Field of view

Sensor size 1/1.7" 1/1.8" 1/1.8" 4K* 1/2" 1/2.3" 1/2.5"
Field of view (H) 36° - 8.6° 36° - 8.6° 35° - 8.5° 30° - 7.4° 30° - 7.2° 27° - 6.7°
Field of view (V) 26° - 6.5° 23° - 5.8° 17° - 4.3° 23v - 5.6° 22° - 5.5° 20° - 5.0°
Field of view (D) 46° - 11° 44° - 10° 40° - 9.5° 39° - 9.2° 38° - 9° 34° - 8.3°
*4K format = 4000 x 2000 pixels
