ML11002 1100萬畫素天文攝影用冷卻CCD
Typical Download Speed: 10 MHz
Typical Maximum Cooling: -55o C Below Ambient
Temperature Stability: 0.1o C
Typical System Noise: 14 e- RMS @ 10 MHz
Non linearity: <1%
Available Shutters: 65 mm (sensor has an electronic shutter)
Lens Mount Compatibility: F-Mount
CCD to Flange Distance: 24.96
Dimensions: 3.70 x 3.70 x 4.77 (94 x 94 x 121.3)
Interface: USB 2.0
Operating Environment: -30o C - 45o C | 10% - 90% Relative Humidity
Power: 12v
Remote Triggering: Standard
Shutter MTBF: 1,000,000
Blooming Protection: 300x
Array Size: 4008 x 2672
Color/Monochrome: Monochrome
Sensor Grades Available: 1, 2
Linear Full Well: 60,000 e-
Mega Pixel: 10.7
Model: KAI-11002
Peak QE: .51
Pixel Size: 9 μm
Sensor Diagonal: 43.3
Sensor Manufacturer: Kodak
Sensor Type: Interline
